System Configuration

• Inverter Capacity: 24 kVA
• Battery Capacity: 30 kWh Lithium
• Solar Capacity: 15.6 kW (650W panels)

 Solar Panel Configuration

• Panel Rating: 650W
• Total Panels: 24 Panels

Total Installed Capacity:
24 × 650W = 15.6 kW

 Expected Solar Generation

• Peak Output: ≈ 10 kW
• Adjusted Output (weather factor): ≈ 7 kW average

Active Solar Time:

• 10 AM – 5 PM (7 hours)

Estimated Daily Generation:
7 kW × 7 hrs ≈ 49 kWh/day

 Battery Storage Capacity

• Battery: 30 kWh Lithium

Provides:

• Strong backup capacity
• Extended runtime support
• Stable and reliable power

 Load Application

Suitable for:

• Homes, offices, and commercial use

Can Power:

• Multiple Air Conditioners
• Water Heater
• Pumping Machine
• TVs
• Lighting systems
• Air Fryers
• Office equipment
• And other heavy appliances

Recommended Maximum Load:
Do not exceed 16.8 kW

 Estimated Run Time (Based on Solar Generation)

 Total Daily Solar Energy Available: ≈ 49 kWh

Load Scenarios:

• Very Light Load (~3.4 kW)
   Runtime: ≈ 14 – 15 hours
• Light Load (~6.7 kW)
   Runtime: ≈ 7 – 8 hours
• Moderate Load (~10.1 kW)
   Runtime: ≈ 4.5 – 5 hours
• High Load (~13.4 kW)
   Runtime: ≈ 3.5 – 4 hours
• Maximum Load (~16.8 kW)
  Runtime: ≈ 2.5 – 3 hours

✔️ Higher load = shorter runtime
✔️ Lower load = longer runtime

 System Performance Summary

• Solar powers loads efficiently during the day
• Battery provides strong backup and stability
• Suitable for high energy demand applications

 Simple Explanation

• Solar generates power during sunlight hours
• Battery stores energy for backup
• Runtime depends on load level

 Final System Summary

• Solar Panels: 24 × 650W
• Solar Capacity: 15.6 kW
• Inverter: 24 kVA
• Battery: 30 kWh Lithium
