24kVA Inverter / 60kWh Lithium Battery / 31.2kW Solar Capacity

System Configuration

• Inverter Capacity: 24 kVA
• Battery Capacity: 60 kWh Lithium
• Solar Capacity: 31.2 kW (650W panels)

 Solar Panel Configuration

• Panel Rating: 650W
• Total Panels: 48 Panels

Total Installed Capacity:
48 × 650W = 31.2 kW

 Expected Solar Generation

• Peak Output: ≈ 20 kW
• Adjusted Output (weather factor): ≈ 14 kW average

Active Solar Time:

• 10 AM – 5 PM (7 hours)

Estimated Daily Generation:
14 kW × 7 hrs ≈ 98 kWh/day

 Battery Storage Capacity

• Battery: 60 kWh Lithium

Provides:

• Very strong backup capacity
• Long runtime support
• Stable and reliable power

 Load Application

Suitable for:

• Homes, offices, and large commercial use

Can Power:

• Multiple Air Conditioners
• Water Heater
• Pumping Machine
• TVs
• Lighting systems
• Air Fryers
• Office equipment
• And other heavy appliances

Recommended Maximum Load:
Do not exceed 16.8 kW

 Estimated Run Time (Based on Solar Generation)

 Total Daily Solar Energy Available: ≈ 98 kWh

Load Scenarios:

• Very Light Load (~3.4 kW)
   Runtime: ≈ 28 – 29 hours
• Light Load (~6.7 kW)
   Runtime: ≈ 14 – 15 hours
• Moderate Load (~10.1 kW)
   Runtime: ≈ 9 – 10 hours
• High Load (~13.4 kW)
   Runtime: ≈ 7 – 8 hours
• Maximum Load (~16.8 kW)
   Runtime: ≈ 5.5 – 6 hours

✔️ Higher load = shorter runtime
✔️ Lower load = longer runtime

 System Performance Summary

• Very high solar capacity supports heavy daytime usage
• Large battery ensures long backup duration
• Suitable for high-demand and continuous operations

 Simple Explanation

• Solar generates power during sunlight hours
• Battery stores excess energy for backup
• Runtime depends on load level

 Final System Summary

• Solar Panels: 48 × 650W
• Solar Capacity: 31.2 kW
• Inverter: 24 kVA
• Battery: 60 kWh Lithium
