System Configuration

• Inverter Capacity: 24 kVA
• Battery Capacity: 40 kWh Lithium
• Solar Capacity: 23.4 kW (650W panels)

 Solar Panel Configuration

• Panel Rating: 650W
• Total Panels: 36 Panels

Total Installed Capacity:
36 × 650W = 23.4 kW

 Expected Solar Generation

• Peak Output: ≈ 15 kW
• Adjusted Output (weather factor): ≈ 10.5 kW average

Active Solar Time:

• 10 AM – 5 PM (7 hours)

Estimated Daily Generation:
10.5 kW × 7 hrs ≈ 73.5 kWh/day

 Battery Storage Capacity

• Battery: 40 kWh Lithium

 Provides:

• High backup capacity
• Extended runtime support
• Stable and reliable power

 Load Application

Suitable for:

• Homes, offices, and commercial use

Can Power:

• Multiple Air Conditioners
• Water Heater
• Pumping Machine
• TVs
• Lighting systems
• Air Fryers
• Office equipment
• And other heavy appliances

Recommended Maximum Load:
Do not exceed 16.8 kW

 Estimated Run Time (Based on Solar Generation)

Total Daily Solar Energy Available: ≈ 73.5 kWh

Load Scenarios:

• Very Light Load (~3.4 kW)
   Runtime: ≈ 21 – 22 hours
• Light Load (~6.7 kW)
   Runtime: ≈ 10 – 11 hours
• Moderate Load (~10.1 kW)
   Runtime: ≈ 7 – 8 hours
• High Load (~13.4 kW)
   Runtime: ≈ 5 – 6 hours
• Maximum Load (~16.8 kW)
   Runtime: ≈ 4 – 4.5 hours

✔️ Higher load = shorter runtime
✔️ Lower load = longer runtime

 System Performance Summary

• High solar capacity supports heavy daytime usage
• Battery ensures strong backup and stability
• Suitable for high energy demand applications

 Simple Explanation

• Solar generates power during sunlight hours
• Battery stores energy for backup
• Runtime depends on load level

 Final System Summary

• Solar Panels: 36 × 650W
• Solar Capacity: 23.4 kW
• Inverter: 24 kVA
• Battery: 40 kWh Lithium
