System Configuration

• Inverter Capacity: 50 kVA
• Battery Capacity: 80 kWh Lithium
• Solar Capacity: 46.8 kW (650W panels)

 Solar Panel Configuration

• Panel Rating: 650W
• Total Panels: 72 Panels

Total Installed Capacity:
72 × 650W = 46.8 kW

 Expected Solar Generation

• Peak Output: ≈ 30 kW
• Adjusted Output (weather factor): ≈ 21 kW average

Active Solar Time:

• 10 AM – 5 PM (7 hours)

Estimated Daily Generation:
21 kW × 7 hrs ≈ 147 kWh/day

 Battery Storage Capacity

• Battery: 80 kWh Lithium

 Provides:

• Extremely strong backup capacity
• Long runtime support
• Stable and reliable power

 Load Application

Suitable for:

• Large homes, offices, factories, and commercial facilities

Can Power:

• Multiple heavy-duty Air Conditioners
• Industrial machines
• Water Heater
• Pumping systems
• TVs & lighting systems
• Office and factory equipment
• And other high-load appliances

Recommended Maximum Load:
Do not exceed 35 kW

 Estimated Run Time (Based on Solar Generation)

 Total Daily Solar Energy Available: ≈ 147 kWh

Load Scenarios:

• Very Light Load (~7 kW)
   Runtime: ≈ 20 – 21 hours
• Light Load (~14 kW)
   Runtime: ≈ 10 – 11 hours
• Moderate Load (~21 kW)
   Runtime: ≈ 7 hours
• High Load (~28 kW)
   Runtime: ≈ 5 – 5.5 hours
• Maximum Load (~35 kW)
   Runtime: ≈ 4 – 4.5 hours

✔️ Higher load = shorter runtime
✔️ Lower load = longer runtime

 System Performance Summary

• Very large solar capacity supports heavy daytime operations
• High battery capacity ensures strong backup and continuity
• Suitable for industrial and high-demand energy usage

 Simple Explanation

• Solar generates large energy during sunlight hours
• Battery stores excess energy for backup
• Runtime depends on how heavy the load is

Final System Summary

• Solar Panels: 72 × 650W
• Solar Capacity: 46.8 kW
• Inverter: 50 kVA
• Battery: 80 kWh Lithium
