3.5kVA Inverter / 5kWh Lithium Battery / 5.2kW Solar Capacity

System Configuration

• Inverter Capacity: 3.5 kVA
• Battery Capacity: 5 kWh Lithium
• Solar Capacity: 5.2 kW (650W panels)

 Solar Panel Configuration

• Panel Rating: 650W
• Total Panels: 8 Panels

Total Installed Capacity:
8 × 650W = 5.2 kW

Expected Solar Generation

• Peak Output: ≈ 3.3 kW
• Adjusted Output (weather factor): ≈ 2.3 kW average

Active Solar Time:

• 10 AM – 5 PM (7 hours)

Estimated Daily Generation:
2.3 kW × 7 hrs ≈ 16.1 kWh/day

 Battery Storage Capacity

• Battery: 5 kWh Lithium

Provides:

• Backup for essential loads
• Support during low sunlight
• Energy stability

 Load Application

Suitable for:

• Homes and small businesses

Can Power:

• Air Conditioner (low capacity)
• TVs
• Lighting
• Laptops
• Small appliances
• And other basic loads

Recommended Maximum Load:
Do not exceed 2.45 kW

 Estimated Run Time (Based on Solar Generation)

Total Daily Solar Energy Available: ≈ 16.1 kWh

Load Scenarios:

• Very Light Load (~0.5 kW)
   Runtime: ≈ 30 – 32 hours
• Light Load (~1.0 kW)
  Runtime: ≈ 16 hours
• Moderate Load (~1.5 kW)
   Runtime: ≈ 10 – 11 hours
• High Load (~2.0 kW)
   Runtime: ≈ 8 hours
• Maximum Load (~2.45 kW)
  Runtime: ≈ 6 – 7 hours

✔️ Higher load = shorter runtime
✔️ Lower load = longer runtime

 System Performance Summary

• Higher solar capacity improves daytime performance
• Battery supports backup and stability
• Suitable for low to moderate energy demand

 Simple Explanation

• Solar generates power during sunlight hours
• Battery stores energy for backup
• Runtime depends on load level

 Final System Summary

• Solar Panels: 8 × 650W
• Solar Capacity: 5.2 kW
• Inverter: 3.5 kVA
• Battery: 5 kWh Lithium
