5kVA Inverter / 15kWh Lithium Battery / 11.7kW Solar Capacity

System Configuration

• Inverter Capacity: 5 kVA
• Battery Capacity: 15 kWh Lithium
• Solar Capacity: 11.7 kW (650W panels)

 Solar Panel Configuration

• Panel Rating: 650W
• Total Panels: 18 Panels

Total Installed Capacity:
18 × 650W = 11.7 kW

Expected Solar Generation

• Peak Output: ≈ 7.5 kW
• Adjusted Output (weather factor): ≈ 5.25 kW average

Active Solar Time:

• 10 AM – 5 PM (7 hours)

Estimated Daily Generation:
5.25 kW × 7 hrs ≈ 36.75 kWh/day

 Battery Storage Capacity

• Battery: 15 kWh Lithium

 Provides:

• Strong backup capacity
• Extended runtime support
• Stable and reliable power

 Load Application

Suitable for:

• Homes and small businesses

Can Power:

• Air Conditioners
• Water Heater
• Pumping Machine
• TVs
• Lighting
• Air Fryers
• Laptops and office equipment
• And other appliances

Recommended Maximum Load:
Do not exceed 3.5 kW

 Estimated Run Time (Based on Solar Generation)

Total Daily Solar Energy Available: ≈ 36.75 kWh

Load Scenarios:

• Very Light Load (~0.7 kW)
  Runtime: ≈ 50 – 52 hours
• Light Load (~1.4 kW)
   Runtime: ≈ 25 – 26 hours
• Moderate Load (~2.1 kW)
   Runtime: ≈ 17 – 18 hours
• High Load (~2.8 kW)
   Runtime: ≈ 13 hours
• Maximum Load (~3.5 kW)
   Runtime: ≈ 10 – 11 hours

✔️ Higher load = shorter runtime
✔️ Lower load = longer runtime

 System Performance Summary

• Very high solar capacity improves daytime performance significantly
• Large battery ensures long backup duration
• Suitable for extended usage and stable power needs

 Simple Explanation

• Solar generates power during sunlight hours
• Battery stores excess energy for long backup
• Runtime depends on load level

 Final System Summary

• Solar Panels: 18 × 650W
• Solar Capacity: 11.7 kW
• Inverter: 5 kVA
• Battery: 15 kWh Lithium
